51117331764 Bumper Trim | Structural & Aesthetic Integration

The 51117331764 Bumper Trim utilizes glass-fiber reinforced polypropylene with CNC-machined surface texturing that replicates OEM light diffusion patterns. Its interlocking edge design maintains 0.5mm panel gap consistency across temperature variations from -40°C to 110°C. The three-stage injection molding process ensures 0.1mm dimensional accuracy for seamless integration with bumper contours.

Aerodynamic underbody channels reduce high-speed wind noise by 19dB compared to standard replacements. The thermal-compensated mounting system allows ±3mm bumper flex without stress fractures, using stainless steel reinforcement clips rated for 75,000 vibration cycles. Pre-aligned sensor cutouts maintain functionality with parking assist systems.

Manufacturing Specifications

• • Material: PP-TD30
• • Wall Thickness: 2.5±0.2mm
• • Surface Roughness: Ra 0.8μm
• • Clip Strength: 45N retention
• • UV Resistance: 8,000 hours

Verified applications include: F10 528i 2014-2016 F11 535d xDrive 2015-2016 F07 ActiveHybrid 5 2014-2016 F18 550Li Luxury
OE Cross References: 51 11 7 331 764 51.11.7.331.764 BM1047130 BM1046130 51-11-7-331-764
