2569024 Switch | Power Window Control Module

Durable 2569024 Switch for Scania R/S Series Power Window Systems

Engineered specifically for Scania R and S Series trucks, this 2569024 Switch delivers precise window control with enhanced durability in demanding transport environments. The switch assembly replicates factory tactile response while implementing upgraded contact materials that withstand over 50,000 actuation cycles without performance degradation. Precision-molded housing features IP65-rated sealing that prevents moisture intrusion in cab environments while resisting vibration-induced failures common in long-haul applications. Integrated LED illumination maintains visibility during nocturnal operations with optimized current draw that prevents electrical system overload. Direct plug-and-play compatibility ensures replacement without wiring modifications, while reinforced mounting tabs withstand repeated operator use without cracking or deformation. The ergonomic contouring matches Scania's driver-centric cockpit design philosophy, maintaining original control positioning and tactile feedback for intuitive operation.

Model Application Compatibility

This power window switch assembly is compatible with Scania R Series (model years 2004-2013) and S Series (2004-2016) trucks across all cab configurations including Normal, Highline, and Topline variants. Direct replacement compatibility confirmed for vehicles equipped with factory window switches referenced as 2569024 and cross-referenced to 2398125. Additional compatible OEM references include 2569025, 2569026, 2569027, 2569028, 2398126, 2398127, 2398128, and 2398129. Installation requires verification of existing switch configuration as certain Scania models implement driver-side master switch units with additional functionality. The component interfaces with Scania's CAN-based electrical architecture without requiring software recalibration or system reset procedures.

Engineering Specifications

Manufactured to withstand transport industry demands, the switch utilizes glass-fiber reinforced nylon housing that maintains dimensional stability from -40°C to 105°C. The 2569024 Switch incorporates self-cleaning twin-contact design where parallel electrical paths provide redundancy in case of contact contamination. Gold-plated copper alloy terminals ensure minimal voltage drop (0.2V maximum at 10A load) while resisting oxidation in high-humidity environments. Tactile response mechanisms are calibrated to 3.2N actuation force with crisp break-over point for positive operational feedback. Integrated circuit protection prevents voltage spike damage to control modules during inductive load switching operations. The sealed rocker mechanism prevents particulate ingress that could impede smooth operation, with pivot points rated for 150,000+ cycles. Backlighting utilizes surface-mounted LEDs with 50,000-hour lifespan powered through PWM-controlled circuits that maintain consistent luminosity regardless of voltage fluctuations.
